| Size |
1200*200*900mm( can be customized) |
| Channel width |
600mm |
| Material Thickness |
1.5mm |
| Passing speed |
35-40 people / minute |
| Communication interface |
RS232 |
| Opening time: |
0.2S |
| Working temperature: |
-25℃ ~ +60℃
|
| Drive motor: |
Brushless DC 24V |
| Life: |
9 million times |
| Power: |
120W
|
Function:
(1) Automatic return function: After the passage process is completed, the brake wings automatically return to the initial blocking position.
(2) Power-off and opening function: When the power is off, the system will automatically open the brake wings to open, which is convenient for evacuation of the crowd and meets fire protection requirements.
(3) Anti-illegal intrusion function: When the card is invalid, there is no card swiping, or the passage is forbidden, the forcible entry into the channel will be regarded as illegal intrusion, and the system will automatically alarm and close the flap.
(4) Anti-reverse intrusion function: Before the end of the passage process in a certain direction, pedestrians entering the passage from the opposite direction will be regarded as reverse intrusion, the system will automatically alarm and close the wing.
(5) Anti-trailing function: The photoelectric switch detects the pedestrian traffic situation, and detects the following phenomenon (the people behind are close to the person in front, intending to pass without swiping the card), the system will automatically alarm and close the brake wings.
(6) Intelligent linkage alarm: including illegal intrusion, reverse traffic and other alarms, which can be linked with other alarm monitoring equipment and can be heard.
(7) Anti-pinching and anti-collision function: A. Infrared anti-pinch: Install multiple pairs of photoelectric switches near the area where the wing is active (anti-pinch area). Once a person or object is detected in the anti-pinch area, the wing automatically stops; The flaps continued to move.
Customized extended functions:
1.Counting and alarm functions.
2. The material of the flap (retractable arm) is acrylic or soft flap. The colors are red, black and blue. The amount can be customized separately.
3. Case material is mainly 304 stainless steel, other materials can also be customized.
4.Remote control switch.
5. Dynamic face recognition.
6. Can add emergency escape function, in the case of special emergency, start by remote button.
7. The communication interface is mainly RS232 / RS485, other interfaces.
8. Fingerprint, face recognition, credit card, QR code pass.
9. Fingerprint, face recognition, credit card, QR code can check on the attendance time.
product detail display
The services that we offer
1. 24hour customerserviceonlineandtimely resolve your service request.
2. We have a one-year warranty for a permanent after-sales service.
3. We have OEM and ODM customized support.
