Highlight:
DC24V Flap Barrier Turnstile
,
DC24V turnstile entrance gates
,
DC24V Construction Site Security Turnstiles
|
Alarm:
|
Yes
|
Anti-collision:
|
Yes
|
|
Anti-reverse:
|
Yes
|
Application Range:
|
Community, Factory, Construction Site, School, Place Of The Resort, Etc
|
|
Driving Motor:
|
DC24V
|
Size:
|
1000*300*980 Mm (can Be Customized)
|
DC24V Construction Site Security Flap Barrier Turnstile Entrance Gates
Hot-Sales Flap Barrie Door Entrance Control Durable Maintenance and Repair Support Turnstile Gate Long Life Application
Durable Maintenance and Repair Support Turnstile Gate Long Life Application Door
FLAP TURNSTILE GATE is a high-performance turnstile gate for pedestrian access control. The turnstile flap barrier gate is a high-tech product aimed at pedestrian access intelligent management, which is an upgraded product based on intelligent tripod turnstile, swing barrier, average wing barrier. This turnstile gate Singapore is well-processed and newly-designed with full functions, high grade, and mainly used in high-grade places such as top-grade communities, intelligent mansions, hotels, subways, ports, clubs, etc.
Functions:
- Turnstile gate Singapore is constructed to control people entering or exiting the restricted area. It is usually used in high pedestrian traffic flow locations in both directions.
- The flap barrier turnstile gate Singapore casing is made of brushed 304 stainless steel which creates a seamless and nice entrance system to blend into most indoor environments.
- It can be integrated with all third-party access control systems (e.g.: RFID access system, Push the button, Fingerprint and face recognition with temperature check).
- In case of emergency, the FlapTurnstile arm will open automatically connecting with the battery or capacitor to allow free passage.
- OpticalFlap Turnstiles are suitable for luxury and elegant entrance solutions.
- The flap turnstile features fast speed, long life, high performance, and high operation dependability
- Alarm function, in case of illegal intrusion and reverse intrusion.
- The infrared sensor will alarm and the LED light will flash to prevent pinching pedestrians.
- Automatic reset function: flap arms will close automatically within 5s in default (can be set) if passenger delays to
- The flap turnstile gate Singapore will stay in the lock if someone wants to burst in without swiping the RFID card.
- LED directional indicator on top and front post
- LED lights on arms are available
- Fully 1.2 mm 304 stainless steel and black tempered glass
- Anti-reverse function, the turnstile alarms if someone wants to enter in the reverse direction.
- Bi-direction or single-direction running are options
|
No
|
Item
|
Data
|
|
1
|
Power Requirements
|
AC 100 to 120V / 200 ~ 240V, 50 / 60Hz
|
|
2
|
Working Temperature
|
-28°C to 60°C
|
|
3
|
Lane Width (mm)
|
635mm ( optional ≤ 850 )
|
|
4
|
Infrared Sensor
|
5 pairs
|
|
5
|
Dimension (L*W*H)
|
1200 * 280 * 1000 ( mm )
|
|
6
|
Cabinet Material
|
SUS304 Stainless Steel
|
|
7
|
Lid Material
|
SUS304 Stainless Steel + Acrylic
|
|
8
|
Barrier Material
|
Tempered Glass ( optional: arcylic)
|
|
9
|
Emergency Mode
|
support
|
|
10
|
Motor
|
brushless motor
|
Access Control System:
Q1:Are you manufacturer?
A1:yes, we are a manufacturer with 13 years history.
Q2: When can you ship the tripod turnstile gate ?
A2: Normal 3-5 days, some stock goods within 24 hours.
Q3: Do you offer access control system too ?
A3: Yes. we have many kinds of access control solutions like cards. QR code. Face recognition.
Q4: Do you support OEM ? A4: Absolutely yes. we can do private design and customization.
Q5: What is the warranty ? A5: 2 years warranty. during this period. Any partrs broken, you will get a new one to replace.
Q6: How to connect it to my access control device ?
A6: There is a signal input port on our gate controller board,its dry contact signal input. it can put into directly using without intergate.
Q7: Does it easy for installation ?
A7: Very easy, just prepare the floor or ground, fix it by Expansion screws.
