Factory Price Access Control Full Automatic Bi-Directional Barrier Swing Turnstile For Supermarket

The length of the cylindrical swing gate turnstile is short, and the function of the pedestrian detection module is limited; however, its size is small and easy to install, so it is very suitable for occasions where the space is small. At the same time, the cylindrical swing gate can also be combined with the visitor system and access control system and applied to the following places:
Write about office spaces: business buildings, government agencies, etc.;
Scientific and educational units: colleges, research institutes, libraries, etc.;
Commercial service places: supermarkets, shopping malls, hotels, clubs, banks, etc.;
Leisure and entertainment venues: parks, scenic spots, playgrounds, etc.
Transportation sites: bus stations, train stations, subway stations, airports, etc.

Technical Parameters:
Overall dimensions: 168MM*height 1050MM
Material: SU304 stainless steel Process: bright brushed type
Material thickness: 1.2mm/1.5mm/2.0mm optional
Transmission mode: standard transmission (passenger)/anti-collision transmission: suitable for bicycles, motorcycles, and electric vehicles.
Channel width: single unit 600mm-900mm
Traffic mode: one-way/two-way
Control software: access control and attendance system/electronic ticketing system/consumption system, etc.
Reading and writing methods: ID card/IC card/ID card/fingerprint face recognition/barcode platform/static tester
Working environment: indoor/outdoor (shade is recommended)
Power supply: AC200V/AV110V (optional) 50HZ
Working environment temperature: -15℃-65℃
Relative humidity: less than 95%, no condensation
Traffic speed: 40/minute
Input interface: relay signal
Normal service life: 3 million times without failure
Communication interface: RS485/TCPIP
Expandable: people counting function, voice alarm function, camera capture function, etc.

Safety Features

• • SUS304 stainless steel body provides ultra-high durability
  • High quality electrical components
  • Barriers swing automatically during emergencies
  • Smooth and quiet operation and without exposed screws
  • Durable electrical components
  • Ergonomic design allows card & fingerprint authentication faster & simpler for users
  • Varied pass mode can be chosen flexibly Standard signal input port, can beconnected with most of the access control board, fingerprint device and scannerother equipment

The turnstile has automatic reset function, if people swipe the authorized cardbut don't pass through within the settled time, it need to swipe card again forentry
Card-reading Recording function: single-directional or bi-directional access canbe set by the users
Automatic opening after emergency fire signal input
Pinch protection
Anti-tailgating control technology :Automatic detection, diagnosis and alarm,sound and light alarm, including trespassing alarm, anti-pinch alarm and anti-tailgating alarm
Self diagnostic and alarm function for convenient maintenance and use.The gate will automatically open when power failure (connect 12V batteryApplications: Supermarket, Campus, Community, Factory, Construction site, etc​
