Product Description:

【Tripod Turnstile Gate Features】

● The unique electromechanical structural design ensures stable and reliable operation of the equipment and supports at least 5 million normal passes;

● The device can be run online, supports remote control and management functions, and can also be run offline on a stand-alone machine.

● The device supports the function of counting people, which can be counted separately for the entry and exit directions.

● The device integrates a voice module, which can customize the voice broadcast content according to user needs.

● Only authorized personnel can pass; unauthorized personnel cannot pass.

● The equipment has an automatic reset function. If there is no passage within the specified time after opening the door, the system will automatically cancel the user's permission for this passage and set the passage time.

● The equipment supports flexible configuration of access status (controlled, free access, prohibited access) in the inbound and outbound directions.

● The device supports memory mode, enabling continuous and fast access

● The device supports flexible selection of normally open and normally closed modes by time period (up to 8 time periods supported).

● The device integrates a wireless receiver, which can be used with a remote control to open the door remotely (one receiver can be associated with up to 32 remote controls, and one remote control can only be associated with 1 receiver)

● The waterlogging prevention height supports up to 690mm, which can prevent the equipment from being unusable after flooding in the rainy season to the greatest extent.

● The equipment has a fire linkage interface. When the fire signal is triggered, the roller pole automatically falls; when the fire signal is restored, the roller needs to be manually raised.

● The equipment supports passage during power outages. When the power is out, the rollers will automatically fall down, allowing people to pass freely to prevent panic.

● It has good anti-trailing effect and strictly prevents unauthorized persons from passing through.

● Unique movement noise reduction design, low-noise operation improves traffic experience

● It has built-in roller rotation damping to avoid hitting the human body during rapid rotation and improve the traffic experience.

● The equipment adopts a graded coding system, which can detect the rotation position of the roller, supports position detection at a minimum of 5 degrees, effectively counts the number of entries and exits, and effectively avoids the deduction of wrong tickets.

● The equipment uses LED to indicate the traffic direction and traffic status, and the brightness of the indicator light can be customized. It is also equipped with a unique movement channel indicator light, which makes the indicator more obvious.

● The equipment adopts special air duct design and device protective cover to improve internal air circulation and solve the problem of condensation in complex environments;

● The equipment has self-detection, self-diagnosis, automatic alarm functions, and sound and light alarm functions.

● It comes with a leakage protector, and the working voltage of the relevant electrical modules of the whole machine does not exceed 24V.

2. Semi-automatic Tripod Turnstile Gate:

◇ Compatible with IC, ID, magnetic cards, barcode cards, anti-static and other control devices

◇ A variety of working modes are available: one-way/two-way

◇ The gate lever is unlocked quickly and reliably

◇ With power outage emergency function, the gate pole will automatically fall down when the power is off, and the hand will lift up the pole when the power is on.

◇ The control panel has counting function and LED digital display function (optional)

◇ The control panel has a memory function

◇ With standard input and output interfaces, it is the first choice of system integrators

3. Mechanical tripod turnstile gate:

◇ Unique positioning and reset system: automatic reset, able to always keep one of its rods in a horizontal position

◇ Tripod Turnstile Gate is a purely mechanical transmission product with no electronic control operation, simple structure and high reliability.

◇ No maintenance required, suitable for places with one-way current limiting management.

Technical Parameters:
